A. Technical appendix
A−15
Festo P.BE−CPX−FB13−EN en 0811c
Slot 1: System parameters
Index Name Length
[byte]
Access Data
record
number
*)
Function no.
16 System data 16 r 16 0 Ū 2
3 Ū 15 (reserved)
17 System parameters 8 r/w 17 4400 (reserved)
4401 Ū 4407
18 Reser ve 64 r/w 18 3416
19 System diagnostic data 8 r 19 1936 Ū 1938
1939 Ū 1943 (reserved)
20 Diagnosis memory
parameters
8 r/w 20 3480 Ū 3487
21 Diagnosis memory
Entry 0
10 r 21 3488 Ū 3497
22 Diagnosis memory
Entry 1
10 r 22 3498Ū. 3507
... Diagnosis memory
Entry ...
10 r ... ...
60 Diagnosis memory
Entry 39
10 r 60 3878 Ū 3887
65 Delete diagnosis
memory
1 w 65 
*)
Siemens S7
Tab.A/8: Slot 1: System parameters
