A. Technical appendix
A−16
Festo P.BE−CPX−FB13−EN en 0811c
Slot 2: Channel−specific module parameters
Index Name Length
[byte]
Access Data
record
number
*)
Function no.
16 Fault mode 64 r 2 3888
17 Fault state 64 r 3 3952
18 Force mode outputs 64 r 4 4016
19 Force state outputs 64 r 5 4080
20 Force mode inputs 64 r 6 4144
21 Force state inputs 64 r 7 4208
22 Global operating system data 40 r 8 4792
*)
Siemens S7
Tab.A/9: Slot 2: Channel−specific module parameters
With slot 3 you have indirect reading and writing access to
the data records (system parameters, module data and
module parameters). In order to do this, assign the 4 bytes of
the command box with: the slot number, the index number
and an offset (byte 4 is reserved).
You can then carry out the
read or write process with the Read Box and the Write Box.
Slot 3: Indexed addressing of the objects
Index Name Length
[byte]
Access Data
record
number
*)
Function no.
16 Command box 4 r/w 9 
17 Read Box 64 r 10 
18 Write Box 64 w 11 
*)
Siemens S7
Tab.A/10: Slot 3: Indexed addressing of the objects
