A. Technical appendix
A−17
Festo P.BE−CPX−FB13−EN en 0811c
Slot 100 Ū 147: Module data and module parameters
Index Name Length
[byte]
Access Data
record
number
*)
Function no.
16 Module configuration 16 r 72 16 + 16 ť m
17 Module series number 4 r 73 784 + 4 ť m
18 Module diagnostic data 4 r 74 2008 + 4 ť m
19 Reser ve 4 r/w 75 3224 + 4 ť m
20 Module nominal configuration 8 r/w 76 4408 + 8 ť m
21 Module parameters 64 r/w 77 4828 + 64 ť m
22 Module parameter records 16 r 78 976 + 16 ť m
23 Diagnosis of all input channels 64 r 79 
24 Diagnosis of all output channels 64 r 80 
25 Module fault mode 64 r/w 81 
26 Module fault state 64 r/w 82 
27 Module force: outputs 64 r/w 83 
28 Module force: outputs 64 r/w 84 
29 Module force: inputs 64 r/w 85 
30 Module force: inputs 64 r/w 86 
m = module number (counting from left to right, beginning with 0)
*)
Siemens S7
Tab.A/11: Module data and parameters
