B. General DP master
B−8
Festo P.BE−CPX−FB13−EN en 0811c
Example: Configuring a CPX terminal
Mod.
no.
Module DP identifier
EN 50170
Comment
0 Field bus node
(FB13: DP slave system status)
40
h
, 00
h
Configured with status bits
1 Digital 8−input module
(I: CPX−8DE)
10
h
Identifier byte used completely
2 Digital 8−input module
(I: CPX−8DE)
10
h
Identifier byte used completely
3 Digital 4−output module
(O: CPX−4DA 2x)
20
h
Only 4 bits of the identifier byte
are used
4 Digital multi I/O module
(Y: CPX−8DE−8DA)
30
h
Identifier byte used completely
5 Digital 4−output module
(*O: CPX−4DA)
00
h
The identifier byte from location 3
is filled with the remaining 4 bits
6 CPA pneumatic interface, set with
DIL switch to 1 Ū 16 valve coils
(VI: CPX type 12: 1−16VS)
21
h
The interface to the pneumatics
must be configured correctly to
correspond to the pneumatic
equipment fitted
Tab.B/3: Example of the configuration of a CPX terminal (see Fig.2/3) with different
modules and MPA pneumatics
