1. Installation
1−6
Festo P.BE−CPX−FB13−EN en 0811c
Note
Always use the correct screws for the manifold base, which
depend on whether the base is made of metal or plastic:
for plastic manifold bases: thread−cutting screws
for metal manifold bases: screws with metric thread.
Fitting Fit the field bus node as follows:
1. Place the field bus node in the manifold base. Make sure
that
the grooves with the power contact terminals on the
bottom of the field bus node lie above the contact rails.
2. Push the field bus node carefully and without tilting as far
as possible into the manifold base.
3. Tighten the screws at first only by hand. Place the screws
so that the self−cutting threads
can be used.
4. Tighten the screws with a TORX screwdriver size T10 with
torque 0.9 Ū 1.1 Nm.
