1. Installation
1−12
Festo P.BE−CPX−FB13−EN en 0811c
Example:
set station number: 5
Example:
set station number: 38
1234 5678
2
0
+ 2
2
=
1 + 4 =
5
1234 56 78
2
1
+ 2
2
+ 2
5
=
2 + 4 + 32 =
38
Fig.1/5: Examples of set station numbers (binary coded)
The following pages contain a summary of the settings for the
station numbers.
