Festo CPX-FB13 - Page 76

2. Commissioning
2−36
Festo P.BE−CPX−FB13−EN en 0811c
Loca
tion
Module DP identifier
Siemens
Input
address
Output
address
0 Field bus node
CPX−FB13: DP slave [status]
64 42 
1 Digital 8−input module
CPX−8DE [8DI]
8DI 43 
2 Digital 4−output module
CPX−4DA [4DO]x2
8DO  42
3 CP interface
CPI:4 bytes I/16 bytes O
192 44 Ū 47 43 Ū 58
4 Digital multi I/O module
CPX−8DE−8DA [8DI/8DO]
8DO 48 59
 MPA pneumatic interface
1)
VMPA−FB−EPL−...
8DO  
5 MPA1 pneumatic module
MPA1S: VMPA1−FB−EMS−8 [8DO]
8DO  60
6 MPA1 pneumatic module
MPA1S: VMPA1−FB−EMS−8 [8DO]
8DO  61
1
) Passive module
Tab.2/17: Input and output addresses for example terminal 3 (see Fig.2/11)
