FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
T
able 4.6 Parameters for Broadband Settings (Continued)
Item
Description
u multicast: this connection is applicable for TR069, voice and
Internet access.
u VOIP: this connection is only applicable for voice
application.
u VOIP_INTERNET: this connection is applicable for voice
and Internet access.
u Other: other connection.
connec-
tion Type
Select the connection type of the WAN port.
u Bridge: the Layer 2 bridge connection mode. This
connection mode can be used when the service type is set
to INTERNET, TR069_INTERNET, VOIP_INTERNET or
Other.
u Route: the Layer 3 router connection mode. This connection
mode can be used for all the service types except for
multicast.
VLAN ID
Sets the VLAN ID of the WAN connection.
The VLAN ID value here should be consistent with that on the
user side of the OLT.
Priority Sets the priority of the VLAN.
Nat Enables or disables the NAT function. Users need to
configure this item
when the service
type is set to
INTERNET, TR069_
INTERNET or
VOIP_INTERNET
and the connection
type is set to Route.
DNS
Relay
Enables or disables the DNS relay
function.
MTU
Enter the maximum transmission unit. It
is recommended to use the default value.
Lan
Binding
Select the LAN port to be bound with the WAN port.
81

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
