154 MS-9050 Series Manual — P/N 52413:F 10/22/2010
Operating Instructions Medical Alert Condition Operation
• Activate appropriate LED on the ANN-LED annunciator (required for this application)
• Each ANN-LED can support up to 10 zones.
Hazard conditions latch. They can be assigned to software zones.
4.9 Medical Alert Condition Operation
Medical alert operation is:
• not intended for nurse call stations (applications) per UL1069.
• not intended for signaling professional medical staff.
• to be used for summoning security guards or other trained personnel within the facility
• intended for Manual activation.
Medical Alert Condition operation will initiate the following events:
• The piezo sounder ¼ second On, ¼ second Off
• The LCD displays a medical alert message along with the device name, type, address,
adjective/noun, associated zones, and time/date
• Communicate the medical alert condition to the Central Station (if the default event code has
been changed from 000 to a reportable event code)
• Relays programmed for medical alert will be activated
• The alarm relay is not
activated
• Fire Alarm NACs will not activate
• SLC NACs (control modules) will activate
• Timers are not started
• Store event in history buffer
• Activate appropriate LED on the ANN-LED annunciator (required for this application)
• Each ANN-LED can support up to 10 zones.
Medical alert conditions latch. They can be assigned to software zones.
4.10 NAC Operation
There are two programmable NACs (Notification Appliance Circuits) resident on the MS-9050UD
main circuit board which can be wired for Style Y (Class B) or Style Z (Class A) . Both NACs may
be programmed as silenceable or nonsilenceable and may also be programmed for steady or coded
operation. Coded operation provides a choice between March Time, Temporal or California cod-
ing.
4.11 Programmed Zone Operation
Each addressable detector and monitor module can be assigned to a maximum of five software
alarm zones. A general alarm zone Z00 may be listed for output (control) points, but it is not nec-
essary to list Z00 for input points, since this is the default zone for all alarm input devices. Zone
Z00 is not activated by supervisory points.
When an input device alarms and is not disabled, it activates all software zones assigned to it. An
output device that is not disabled is turned on when any of the software zones to which it is pro-
grammed become active. Only fire alarms can turn on any of the two main NACs.
Note that hazards/tornado alerts do not turn on the two main NACs.
