162 MS-9050 Series Manual — P/N 52413:F 10/22/2010
Operating Instructions Read Status
4.22.2 Zones
Pressing 2 while viewing Read Status Screen #1 will cause the following screens to be displayed:
From the preceding screens, the control panel operator can view:
• Zones Installed - all software zones programmed into the system (20 maximum)
• Zones Enabled - all software zones that are enabled
• Zones Disabled - all software zones that have been disabled
• Special Purpose - on or off programming for Special Purpose Zones 17 reserved for PAS, 18
reserved for Pre-signal and 19 reserved for Two Stage Operation
• Zone Type - the Type assigned to each installed zone (default is Alarm)
4.22.3 Power
Pressing 3 while viewing Read Status Screen #1 will cause the following screens to be displayed:
A real-time display of the control panel voltages can be used to determine if a problem exists in the
system.
READ STATUS
1=SYSTEM POINT
2=ZONES
3=POWER
Read Status Screen #1
ZONES
1=ZONES INSTALLED
2=ZONES ENABLED
3=ZONES DISABLED
Zones Screen #1
ZONES
1=SPECIAL PURPOSE
2=ZONE TYPE
3=FUTURE USE
Zones Screen #2
POWER
BATTERY 27.21V
ANN-BUS PWR 27.75V
CHARGER 27.75V
Power Screen #1
POWER
SYSTEM PWR 27.60V
Power Screen #2
