Operating Instructions Read Status
4.22.10 ANN-BUS
Pressing 1 while viewing Read Status Screen #4 will display the following screens:
Pressing 2 for Modules Installed, while viewing ANN-BUS Screen #1 will display screens with
ANN-BUS Addresses 1 through 8. Selecting an address will display information about the device
which has been assigned that address.
Pressing 3 for ANN-S/PG Options, while viewing ANN-BUS Screen #1 will display screens detail-
ing the setting for the ANN-SPG printer installed. This information includes:
• Port Parallel/Serial
• Printer Supervision Yes/No
• Off Line Timer setting
•Baud Rate
• Data Bits
•Parity
• Stop Bits
Pressing 1 for ANN-80 Options, while viewing ANN-BUS Screen #2 will display screens detailing
the settings for this device. The information includes:
• Piezo Enable/Disable
• Lock Enable/Disable
• Acknowledge Button Enable/Disable
• Silence Button Enable/Disable
• Reset Button Enable/Disable
• Drill Button Enable/Disable
Pressing 2 for ANN-SECONDARY Options, while viewing ANN-BUS Screen #2 will display
screens detailing the settings for this device and would display the following screen:
ANN-BUS
ENABLED
2=MODULES INSTALLED
3=ANN-S/PG OPTIONS
ANN-BUS Screen #1
ANN-BUS
1=ANN-80 OPTIONS
2=ANN-SECONDARY
ANN-BUS Screen #2
ANN-SECONDARY
ENABLED
ANN-SECONDARY Screen #2
