168 MS-9050 Series Manual — P/N 52413:F 10/22/2010
Operating Instructions Read Status
4.22.13 Service Terminal
Pressing 1 for Ring Count, while viewing Read Status Screen #5 will display the following screens:
4.22.14 Print
To print program data or control panel status, press 2 while viewing Read Status Screen #5. The
following screens will be displayed:
Pressing 1 while viewing Print Screen #1 allows the user to print the History file which will detail
all of the system activities since the file was last cleared from memory.
Pressing 2 while viewing Print Screen #1 allows the user to print the Walktest log which will detail
all of the system activations during walktest since the log was last cleared. Refer to “Walktest” on
page 106 for additional information on the display.
Pressing 3 while viewing Print Screen #1 allows the user to print the Walktest summary. This
screen will display a total of the tested detectors, tested modules, untested detectors and untested
modules for the current walktest session. Refer to “Walktest” on page 106 for additional informa-
tion on the display.
Pressing 1 while viewing Print Screen #2 allows the user to print the detector data for each address-
able smoke detector connected to the system. A printout, similar to the following example, will be
generated if an optional printer is connected to the FACP.
READ STATUS
1=RING COUNT
2=PRINT
3=TIME-DATE
Read Status Screen #5
SERVICE TERMINAL
RING COUNT 03
Service Terminal Screen
READ STATUS
1=SERVICE TERMINAL
2=PRINT
3=TIME-DATE
Read Status Screen #5
PRINT
1=HISTORY
2=WALKTEST LOG
3=WALKTEST SUMMARY
PRINT
1=DETECTOR DATA
2=DACT SUMMARY
3=EXIT PRINTING
Print Screen #2
Print Screen #1
To Next Page
