Programming Master Programming Level
Type Monitor
Using the PK-CD Upload/Download utility program, unique user-defined monitor types can be cre-
ated and loaded into the FACP for later use. The FACP response to the activation of a user-defined
type is the same as most previous standard types in the list, thus allowing a variety of user-defined
types and responses. To select the type of monitor module being programmed, press the 2 key
while viewing the Edit Monitor Screen #2. This will cause the control panel to display the first
Monitor Type Screen as illustrated below
To view additional Monitor Type Screens, press the down arrow key. While viewing one of the
Monitor Type screens, select the type of monitor module being programmed by pressing the corre-
sponding keypad number key. The display will return to the Edit Monitor Screen #2 which will
show the new type selection. The following table lists all of the Monitor Types available for pro-
gramming and their respective functions.
Monitor module type selection will affect the function of the point as follows:
Monitor Type Action When Activated
Pull-Station Fire Alarm
User-Defined-1 Fire Alarm
Waterflow Fire Alarm Delayed (uses waterflow delay)
User-Defined-2 Fire Alarm Delayed (uses waterflow delay)
Monitor Fire Alarm
User-Defined-3 Fire Alarm
Future Use Future Use
Future Use Future Use
Smoke-Conventional
1, 2
Fire Alarm
User-Defined-5
2
Fire Alarm
Heat-Conventional
2
Fire Alarm
User-Defined-6
2
Fire Alarm
Medic-Alert
3
Piezo, latching
User-Defined-7 Piezo, latching
Hazard-Alert
3
Piezo, latching
User-Defined-8 Piezo, latching
Tornado-Alert
3
Piezo, latching
User-Defined-9 Piezo, latching
Future Use Future Use
Future Use Future Use
Tamper Supervisory, nonlatching (tracking)
User-Defined-11 Supervisory, nonlatching (tracking)
Supervisory Supervisory, latching
User-Defined-12 Supervisory, latching
Supervisory-AR
4
Supervisory, nonlatching (tracking)
User-Defined-13 Supervisory, nonlatching (tracking)
HVAC OVRRIDE
5
Switch Supervisory, nonlatching (tracking)
Power-Monitor AC Fault
Table 3.1 Monitor Types
EDIT MONITOR
1=ENABLED
2=TYPE MONITOR
Edit Monitor Screen #2
MONITOR TYPE
1=PULL-STATION
2=USER-DEFINED-1
3=WATERFLOW
Monitor Type Screen #1
To Next Page
