MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010 119
Master Programming Level Programming
Annunciator addressing is specific to the MS-9200UDLS control panel. The following table
describes the annunciator addresses and the corresponding addressable devices that will be
annunciated at each annunciator address.
The MS-9200UDLS must be programmed for the annunciators installed on the system. Refer to
“Annunciators” on page 117 for information on annunciator programming. Make certain to
program the annunciator addresses that have been physically installed on the system.
ACS Annunciator Address Annunciator Displays the Following Points
1 8 General System Status Points & Zones 1 - 56
2 Zones 57 - 99 & 4 NACs
3 SLC Loop, Module Addresses 1 - 64
4 not used
5 SLC Loop, Module Addresses 65 - 99
6 not used
7 not used
8 SLC Loop, Detector Addresses 1 - 64
9 not used
10 SLC Loop, Detector Addresses 65 - 99
11 not used
12 not used
13 not used
14 not used
15 not used
16 not used
17 not used
18 not used
19 not used
20 8 General System Status Points & Zones 1 - 56
21 Zones 57 - 99 & 4 NACs
22 SLC Loop, Module Addresses 1 - 64
23 not used
24 SLC Loop, Module Addresses 65 - 99
25 not used
26 not used
27 SLC Loop, Detector Addresses 1 - 64
28 not used
29 SLC Loop, Detector Addresses 65 - 99
30 not used
31 not used
32 not used
NOTE: The 8 General System Status Points include the following:
• General Alarm
• General Trouble
• General Supervisory
• Alarm Silenced
• System Off Normal
• AC Loss
• Battery Fault
• NAC Fault
