120 MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010
Programming Master Programming Level
ANN-BUS Options
Pressing 3 for ANN-BUS Options, while viewing the Annunciators screen, will cause the following
screens to be displayed:.
A printer module, graphic annunciator module, LCD annunciator module, LED annunciator
module and relay module can be programmed into the MS-9200UDLS system. These devices
communicate with the FACP over the ANN-BUS terminals on the control panel.
Two ANN-BUS circuits are available on the MS-9200UDLS. Press 1 to configure the Primary
ANN-BUS or press 2 to configure the Secondary ANN-BUS. The following screen will be
displayed for either ANN-BUS circuit.
ANN-BUS Enabled
The ANN-BUS must be enabled if any modules are connected to the ANN-BUS terminals. To
enable the ANN-BUS, press 1 while viewing ANN-BUS screen #1 so that the display reads ANN-
BUS Enabled Yes. Each press of the 1 key will cause the display to toggle between ANN-BUS
Enabled Yes and ANN-BUS Enabled No.
Modules Installed
If an ANN-BUS module is installed, press 2 for Modules Installed to select ANN-BUS addresses
for the module(s). The only difference between the two programming screens are the addresses.
The Primary Bus module addresses will have a prefix of “1-” while the Secondary Bus module
addresses will have a prefix of “2-”. The following screen will be displayed for either bus circuit.
ANNUNCIATORS
1=TERM ENABLED NO
2=ACS OPTIONS
3=ANN-BUS OPTIONS
Annunciators Screen #3
ANN-BUS SELECT
1=PRIMARY
2=SECONDARY
3=ANN-BUS OPTIONS
ANN-BUS Select Screen
PRIMARY ANN-BUS
1=ENABLED NO
2=MODULES INSTALLED
3=AUTO-CONFIGURE
ANN-BUS Screen
ANN-BUS MODULES
1=ADDR. X-1 NONE
2=ADDR. X-2 NONE
3=ADDR. X-3 NONE
ANN-BUS Modules Screen #1
