PCB and Housing – LCD Model
The PCB, which contains the capacitive touch
buttons and LCD, is mounted within a plastic
housing. The PCB housing is clipped into the
console at the bottom, and secured with four
screws along the top.
Facia – LED Model
Is a clear plastic molded insert with an adhesive
backed touch panel fitted
PCB and Housing – LED Model
The PCB, which contains the touch buttons and
LED’s, is mounted within a plastic housing. The
PCB housing is clipped into the console at the
bottom, and secured with four screws along the
top.
