1 SPECIFICATIONS
1.1 Model Information
AquaSmart introduces the new Fisher & Paykel model numbering system, which provides a
clearer description of the product and its features. The new model numbering system will come in
to affect with each new model released.
The model identification is explained below.
W
Washer
W
Washer
W
Washer
L
Low (Profile Agitator)
L
Low (Profile Agitator)
L
Low (Profile Agitator)
37
Capacity cu/ft (3.7) IEC
37
Capacity cu/ft (3.7) IEC
37
Capacity cu/ft (3.7) IEC
T
Top Loading
T
Top Loading
T
Top Loading
26
26 inches wide
26
26 inches wide
26
26 inches wide
C
LCD Screen
D
LED Display
K
LED Display Non Dispense
W
White
W
White
W
White
2
Series
2
Series
2
Series
1.2 Dimensions
Height to lid
Open 55.5in – 56.7in / 1410mm – 1440mm
Closed 37.4in – 38.6in / 950mm – 980mm
Height to console 39.8in – 41 3in / 1010mm – 1050mm
Width 26in / 650mm
Depth 26in / 650mm
Inlet hose length 47.24in / 1200mm
Packed weight 133.4lb / 60.5 kg
Unpacked weight 114.64lb / 52.0kg
Note: The exact height of AquaSmart
™
is dependent on how far the feet are inserted into
the base of the machine.
1.3 Maximum Capacity (AS/NZS 2040.1:2005)
Dry Weight: 15.4 lb / 7 kg
1.4 Water Consumption
Load Size Regular High Efficiency*
15.5 lb / 7kg 21.7 G / 82 litres
11 lb / 5kg 18.2 G / 69 litres
6.6 lb / 3kg 15.85 G / 60 litres
2.2 lb / 1kg 14.5 G / 55 litres
*Regular High Efficiency is the default wash cycle for AquaSmart 
1.5 Water Fill Temperature (Approximate Factory Settings)
Supply
Water Fill Temp*
Hot
140F (60c)
Hot / Warm
115F (46
o
C)
Warm
102F (39
o
C)
Warm / Cold
91F (33
o
C)
Cold Plus
68F (20
o
C)
Cold Supply temperature
Recommended hot water inlet temperature 149F (65
o
C) (Maximum)
*Dependent on hot and cold supply temperatures and water pressures
