5 VOLTAGE AND RESISTANCE READINGS FROM
THE CONTROLLER
5.1 Voltage Readings
1 2
3 4 6 5 7
8
1. Water Valves
Varies between 13 – 22V DC
Note: Accurate voltages can only be
obtained by using a True RMS multimeter.
2. Supply voltage
110V AC
3. Wash Motor
No accurate readings are possible.
4. Pump Motor
No accurate readings are possible.
5. RPS
6. Display Module
7. Lid lock
8. Thermistor
0 – 5 V DC
Pulses up to 30V when locking, when
locked, sits at approx 10V DC
5 V DC
Should always
be 15V DC
A
CBA
Individual phases will be 15 or 0
volts
,
will chan
g
e as motor turns
