Replacement parts
11.2 Spare parts drawing and spare parts list
70 Edition 09/2022 M4602-02en
)1'66%
)1'6+%
)1'%
① Version with thermal circuit breaker / with EOC transmitter EOC
② Position of the fusible safety plugs for FLUDEX size 887
Part number Designation Part number Designation
2 Coupling part 2 (N-EUPEX) 112 Cylinder-head screw E
3 Coupling part 3 (N-EUPEX) 114 O-ring D*
8 Brake disk 117 O-ring D*
10 Coupling part 10 (N-
EUPEX)
118 Parallel key
11 Coupling part 11 120 Hub carrier part
12 Flexible elements (N-
EUPEX)
122 Stepped ring E
