9 Measurement
FLUXUS F502TE 9.4 Display of measured values
87
UMFLUXUS_F502TEV1-5EN, 2020-05-29
9.4 Display of measured values
The measured values are displayed during the measurement as follows:
9.4.1 Value of the sound speed
The sound speed of the fluid can be displayed during the measurement by pressing .
If an approximate range for the sound speed has been entered in the program branch Parameter and the transducer
distance has been optimized afterwards, it is recommended to write down the sound speed for the next measurement. By
doing so, it will not be necessary to repeat the fine adjustment.
Write down the fluid temperature as the sound speed depends on it. The value can be entered in the program branch
Parameter.
9.4.2 Adjustment of the display
During the measurement, the display can be adapted in order to display 2 measured values at the same time (one in each
line of the display). This does not affect totalizing, storing of measured values, transmission of measured values, etc.
The following information can be displayed in the upper line:
Tab. 9.4: Standard values for signal optimization
transducer frequency max. difference between the optimum and the entered transducer distance [mm]
M 10
P 8
Q 6
Notice!
If the transducer distance is changed during the measurement, the consistency check has to be repeated once again.
display explanation
Thermal energy designation of the physical quantity
+18.8 kW values of the totalizers, if activated
Tx temperatures assigned to the channel and their difference if the temperature is measured
full date and time at which the data logger will be full, if activated
L transducer distance
Rx alarm state indication, if activated and if alarm outputs are activated
δc difference between the measured sound speed and the sound speed of a selected reference fluid,
if activated
Thermal energy
0.4 kW
