Flexim FLUXUS F502TE User Manual

13 Outputs
FLUXUS F502TE 13.1 Installation of a binary output
99
UMFLUXUS_F502TEV1-5EN, 2020-05-29
Function test of the binary output
The function of the output can now be tested.
• Connect an external measuring instrument to the terminals of the installed output.
• Select Opto-Relay OFF in the scroll list Output Test to test the de-energized state of the output.
• Press ENTER. Measure the resistance at the output. The value has to be high ohmic.
• Select yes to repeat the test or no to return to the menu item SYSTEM settings.
• Press ENTER.
• Select Opto-Relay ON in the scroll list Output Test to test the energized state of the output.
• Press ENTER. Measure the resistance at the output. The value has to be low ohmic.
• Select yes to repeat the test or no to return to the menu item SYSTEM settings.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\...\B1 Output Test\Opto-Relay OFF
Special Funct.\...\B1 Output Test\B1=ON\Again?
Special Funct.\SYSTEM settings\Proc. outputs\...\B1 Output Test\Opto-Relay ON
Special Funct.\...\B1 Output Test\B1=ON\Again?
