FLIR M5104 User Manual

Connecting a PTZ Camera (M5100 Series)
21
2. Click the Pattern tab.
3. Under Pattern, enter the pattern you would like to configure.
4. Move the camera into the desired start position and click Begin.
5. Move the camera into the desired end position and click End.
To run a pattern:
• Under No., select the number of the pattern you would like to go to and click
.
21.2.4 Auto Scan
An auto scan automatically cycles between a left and right point.
To create a new auto scan:
1. Click
to open the aux menu.
2. Click the Border tab.
3. Move the camera into the desired left position and click Left.
4. Move the camera into the desired right position and click Right.
To run an auto scan:
• Click
.
#LX400096; r.45547/45547; en-US
169

FLIR M5104 Specifications

General

Brand	FLIR
Model	M5104
Category	DVR
Language	English
