Page #188 background imageLoading...
Page #188 background image
M5100 Series System
Specifications
25
System
Operating System Linux (embedded)
Pentaplex Simultaneous view, record, playback, backup & re-
mote monitoring
Number of Channels 4/8/16 channel
Inputs/Outputs
Video IN 4/8/16 × 1Vp-p, BNC
BNC Video OUT No
VGA OUT Yes
HDMI Yes
Audio IN
Audio IN 1 channel (RCA), supports 2-way talk
Audio OUT Audio OUT 1 channel (RCA), supports 2-way talk
USB Port USB 2.0 x 2 (1 at the back, 1 at the front)
Alarm IN None
Alarm OUT
None
Video Output Resolution
4 ch: 4MP
8/16 ch: 4k
PTZ Control BNC-CVI + RS-485 Pelco D & P Protocol
Display
Live Display 4 ch: 1, 4
8 ch: 1, 4, 8
16 ch: 1, 4, 8, 9, 16
Live Display Speed 4 ch: 120 NTSC, 100 PAL
8 ch: 240 NTSC, 200 PAL
16 ch: 480 NTSC, 400 PAL
OSD ON/OFF
System Navigation USB mouse, IR remote controller, front panel
Motion Area Setting Fixed grid 396 (22x18) NTSC&PAL
Sensitivity Levels
100
Firmware Upgrade Via USB device and network
User Authority By user group
Time Synchronization Auto time sync by NTP server
Recording
Video Compression
H.264+
Audio Compression G.711
Recording Resolution
NTSC: 4MP(2560×1440), 3MP(2304×1296),
1080p (1920x1080), 720p (1280x720), 960x480,
704x480, 352X480, 704x240, 352x240, 176x120
PAL: 4MP(2560×1440), 3MP(2304×1296), 1080p
(1920x1080), 720p (1280×720), 960×576,
704×576, 352×288, 176×144
#LX400096; r.45547/45547; en-US
178
