ROTADISK Pneumatic Actuator RD & RDF
Operating Manual – BA3002 EN
8 Repair
Page 52 of 79
32. Screw the locking pin (threaded pin) [5] into the drive shaft [4].
33. Place the black support ring [17] onto the shim bushing [8].
34. Fit the position indicator [16].
35. Check the ROTADISK Pneumatic Actuator for correct direction of rotation and
leaks.
✓ Replacement of the seals is completed.
[16]
[8]
[17]
[5]
[4]
