Section 4: Using the Model 9100: Mark/Period Function 4.10-3
Final Width = 215mm
4.10.3 Screen Keys
4.10.3.1 Bottom Screen Keys
Hz Selects
Frequency when Mark/Period or % Duty is active.
Selects Mark/Period when Frequency or % Duty is active.
% DUTY
Selects % Duty when Frequency or Mark/Period is active.
4.10.3.2 Right Side Screen Keys
A. Digit Edit Facility Keys operate on the value marked by the cursor.
X 10 Multiplies the marked value by ten.
÷ 10 Divides the marked value by ten.
INVERT Inverts the Mark/Space ratio of the waveform. The
INVERT key is only
available when the cursor is selecting the
Mark interval.
± Reverses the polarity of the marked value. The ± key is only available
when the cursor is marking either the High or Low Level value.
B. Direct Edit Facility Right side keys operate on the value in the edit box, and
acting in place of the ↵ key, exit from Direct Edit back to
Digit Edit; then set the value as evaluated in the box.
i. Mark or Period Intervals
µ s Evaluates the number in the box in Microseconds.
ms Evaluates the number in the box in Milliseconds.
s Evaluates the number in the box in Seconds.
The selected
Mark or Period interval value is set into the highest resolution
available to its magnitude.
ii. Selected High or Low Level Value
V Evaluates the number in the box in Volts.
The selected High Level value or Low Level value is set into a resolution of four
significant digits with two decimal places.
