Section 4: Using the Model 9100: Mark/Period Function 4.10-5
Final Width = 215mm
4.10.4.2 'Mark' and 'Period' Time-Interval Editing
Mark and Period time-interval values can be changed using 'Digit' and 'Direct' edit
facilities. The editing processes are not described in Section 3, but follow the same
general rules as for editing voltages.
The resolution of time-interval values is set at six significant digits, except for the shortest
span of intervals at four significant digits. This leads to four repetition period spans of
constant resolution. The '
Mark' interval value must always be less than the 'Period'
interval.
The thresholds between resolutions of Mark interval and of Period interval are given in
paras 4.10.5.1.
Analog hardware configurations for time-interval change are given in paras 4.10.5.2.
