4.21-12 Section 4: Using the Model 9100: AC Harmonics Function - Operation
Final Width = 215mm
Sequence of Operations
Refer to the table of UUT calibration points in the UUT Manufacturers Calibration Guide.
Follow the correct sequence of calibration stages as directed by the guide, and carry out
the following operations (1) to (5) at each stage.
1. 9100 a. Use the front panel controls to set the 9100 Main Output to the
UUT cal point frequency, voltage and current, entering High
Voltage State if the cal point has been assigned to that State. The
default High Voltage State boundaries are shown in Fig. 4.21.1.
b. Select the required Harmonic parameters.
2. UUT Select the correct range for the cal point.
3. 9100 a. Set Output ON.
b. Note the UUT reading
4. UUT a. If a UUT calibration adjustment is provided, adjust the UUT to
equal the reading on the 9100 screen.
b. If no adjustment is provided on the UUT, record the UUT
reading at the calibration point
5. 9100 Set Output OFF.
4.21.7.3 Using the 9100 as an Adjustable Source
The following procedure assumes that the instrument is in Manual Mode. In the case of
difficulty, re-read Section 3.3.1. Familiarity with the methods of editing screen values is
also assumed (Section 3).
Calibration Setup
1. Connections Connect the 9100 to the UUT and ensure that both instruments
are powered ON and warmed up.
2. UUT Select AC Harmonics function.
3. 9100 Ensure that the 9100 is in AC Harmonics Function with Output
OFF.
To Next Page
