5.3.3 Selection of Procedure Mode —
Entry Menus Common to All Procedures
(A flow chart summarizing the access to Procedures is given at Paras 5.3.3.13 — Fig. 5.3.1)
5.3.3.1 PROC Key
Procedure mode is entered by pressing the '
PROC
' screen key on the bottom row of the
Mode Selection menu screen (or after Power On when the Procedure mode is set as the
power-on default in Configuration mode).
5.3.3.2 Procedure Mode Display at Entry
OK
When Procedure mode has been
successfully entered, the 9100 starts by
presenting the 'Select USER NAME ...'
display:
5.3.3.3 Is Your Name on the List?
If you are on the list, use cursor keys to select your name, then press the 'OK' screen key.
If Your Name is NOT on the List:
Use the alpha-numeric keypad to write your name (12 characters max.) on the screen
[1]
.
It will appear at the bottom of the screen as you type. Then press the '↵' key or the 'OK'
screen key, after which the screen will change to select the manufacturer or model to be
tested, except that further progress will require a procedure card to be inserted into the
'PROCEDURE
MEMORY
CARD
' slot (refer to paras 5.3.3.4, overleaf).
The list can be cleared only by entering
CONFIG
Mode, using the password and pressing
the '
MORE
' screen key, then using the '
CLEAR USER LIST
' facility.
Select USER NAME from list or type
in a new name using the keypad.
C F BARNES
F J BLOGGS
J K FLIPFLOP
[1] Writing Your Name on the Screen
For alphabetical characters, there are
two shift keys: '
' (blue — left) and
'
' (green — right) on the bottom row
of the keypad. The numeric keys have
colour-coded alphabetical characters
printed on left and right. Press and
release the appropriate shift key then
the alphabetic character key in order to
spell out your name.
Only UPPER CASE characters are
available from the keypad.
After one of the shift keys has been
pressed, and before pressing the '↵'
key, the corresponding shift icon is
presented at the bottom right of the
screen.
To Next Page
