b. No Procedure Card in Slot, but a UUT Model's Procedures Resident in RAM
If, on a previous occasion since the most-recent power-on, a UUT model was selected
from the Select Model screen menu, the 9100 will have downloaded all the procedures
for the selected model into internal RAM.
If, on this occasion, no Procedure memory card has yet been inserted into the slot, and
procedures are still resident in the RAM, (see 5.3.3.6), then a message similar to the
following will appear on the screen:
ABORTMODEL
NEW
CARD
A choice is given: whether to use the loaded procedures, or to insert a new card to load
a different model's procedures.
For the same model, merely press the 'MODEL' screen key and the 9100 will transfer
to the 'Enter the SERIAL NUMBER ...' screen.
For a different model, insert the card required for the UUT into the 'Procedure' slot, push
firmly home, and press the 'NEW CARD' screen key for the sequence to continue.
After pressing 'NEW CARD', the 9100 will transfer to the 'Select MANUFACTURER'
menu screen if more than one manufacturer is listed in the procedure card, or to 'Select
MODEL' screen if only one manufacturer is listed.
ABORT returns to the 'Select USER NAME ...' screen.
Refer to paras 5.3.3 13, Fig 5.3.1.
The DM25XT model
has been loaded previously.
Press MODEL to use this model or
insert a procedure card and then press
NEW CARD to continue.
