5.3.3.5 Select the Subject UUT Manufacturer
(Only available if more than one manufacturer is listed in the Procedure Card)
By the time the 'Select MANUFACTURER' screen has been successfully opened, the
9100 will have extracted a list of the manufacturers whose models' procedures are
contained in the Procedure card memory. These it displays on the screen for the user to
choose. For example:
NEW
CARD
ABORTOK
Select MANUFACTURER using cursor keys.
Press NEW CARD to read another card.
MANUF 1
MANUF 2
If the wrong card has been inserted:
Remove that card, insert another, then press the NEW CARD screen key to tell the 9100
that a different card has been inserted.
More than one manufacturer listed in the new card:
The 9100 lists the manufacturers whose models' procedures are resident in the new
card
Only one manufacturer listed in the new card:
The 9100 transfers to the 'Select MODEL' screen if only one manufacturer is listed.
Correct manufacturer selected:
After selecting the required manufacturer, pressing the OK screen key will cause the 9100
to transfer to the 'Select MODEL' menu screen.
ABORT
returns to the 'Select USER NAME ...' screen.
Refer to paras 5.3.3 13, Fig 5.3.1.
