5.3.3.7 Enter the Serial Number of the Subject UUT
Having selected the UUT model, the 9100 asks for the serial number to be entered so that
any results can be identified. This is done on the following screen:
Enter the UUT's Serial Number:
Use the alpha-numeric keypad to write the serial number (20 characters max.) on the
screen
[1]
. It will appear at the bottom of the screen as you type. Then press the '↵' key
or the 'OK' screen key, after which the screen will change to select the type of procedure
required
ABORT returns to the 'Select USER NAME ...' screen.
Refer to paras 5.3.3 13, Fig 5.3.1.
5.3.3.8 Select the Procedure for the Subject UUT Model
When the 'Select PROCEDURE' screen is opened, the 9100 will have already downloaded
all the procedures for the selected model from the Procedure card memory into internal
RAM. The 9100 displays a list of these on the screen for the user to choose:
ABORTOK
Select PROCEDURE using cursor keys.
Confirm with OK.
Adjustment Only
1 Year Verification
ISO9000 Verify
Verify Pass/Fail
ISO9000 Pass/Fail
[1] Writing the Serial Number
For alphabetical characters, there are
two shift keys: ' ' (blue — left) and
' ' (green — right) on the bottom row
of the keypad. The numeric keys have
colour-coded alphabetical characters
printed on left and right. Press and
release the appropriate shift key then
the alphabetic character key in order to
spell out your name.
Only UPPER CASE characters are
available from the keypad.
After one of the shift keys has been
pressed, and before pressing the '↵'
key, the corresponding shift icon is
presented at the bottom right of the
screen.
