Types of Procedure (Procedure Cards supplied from the Procedure Library)
Variants of three basic procedures (Adjustment Only; 1Year Verification and Verify
Pass/Fail) can be found in the Procedure cards available in the manufacturer's UUT
Calibration Procedure Library (sub-section 1.4). The Model 9010 provides for users to
generate other procedures. The titles of all procedures present in a Procedure card for a
model will be listed on the 'Select PROCEDURE' screen.
Adjustment Only
The procedure will cause the 9100 to provide the correct outputs for each of the
Manufacturer's recommended test points for adjustment of the subject UUT model. The
identity of adjustment controls, target values and limits are presented on the screen for
the convenience of the user, who will also decide whether the adjustment was successful,
and record pass/fail status. The procedure is described in sub-section 5.4.
1 Year Verification
The 9100 provides the correct outputs for each of the Manufacturer's recommended test
points used to verify the full performance of the subject UUT model. Users can slew the
output to determine the UUT error. 'Style 1' printed results will list these errors. The
procedure is described in sub-section 5.5.
ISO9000 Verify
This is a variant of 1 Year Verification, different in that the 9100 provides a wider range
of test points to verify performance in greater detail than is recommended by the
Manufacturer.
Verify Pass/Fail
The 9100 provides the correct outputs at each of the test points, for the user to check
whether the UUT verifies within its specification. Pass/Fail only is printed on the report.
The procedure is described in sub-section 5.6.
ISO9000 Pass/Fail
This is a variant of Verify Pass/Fail, different in that the 9100 provides a wider range of
test points to check the specification in greater detail than is recommended by the
Manufacturer.
To Select a Procedure
Use either the
and cursor keys, the spinwheel, or a mouse to highlight the
required procedure, then press 'OK'. the 9100 will transfer to the appropriate menu
screen. Refer to the procedure description.
ABORT returns to the 'Select USER NAME ...' screen.
Refer to paras 5.3.3 13, Fig 5.3.1.
