5.3-10 Section 5: Using the Model 9100: Procedure Mode
Final Width = 215mm
5.3.3.9 Procedures — Card-Based Operating Instructions
Selection of UUT Model
When the model of UUT has been chosen from the menu (derived from the procedure
card), all procedures for the selected model are automatically downloaded into the 9000's
internal memory, and the selected procedure no longer requires the card, as it will be
programmed from the internal memory. Once the procedure has progressed this far, the
procedure card can be removed and used to program other Model 9100 units.
Procedure Activation
Once the type of procedure has been selected, the downloaded user-interactive program
will be run by the 9100. Subsequent instructions appearing on the screen will be derived
from the programmed sequences.
No further routine instructions are given here, as they may vary from model to model and
are developed within the programmed sequences. However, the 9100 is programmed
also to interrupt procedures and communicate with the user when certain events occur.
Among these, the two most important are those of 'Abort' and 'End'.
