3-36 Section 3: Model 9100 Controls: Working with Front Panel Controls — Tutorials
Final Width = 215mm
3.4.4.6 Incrementing a Digit using the Spinwheel
Slowly rotate the Spinwheel Clockwise. The marked digit increases.
.
.
+
+
3.4.4.7 Decrementing a Digit
Slowly rotate the Spinwheel Counter-Clockwise. The marked digit decreases.
.
.
+
+
3.4.4.8 Continuous Increment/Decrement
For continuous automatic action, keep rotating the Spinwheel in the required direction.
Note that the next (more significant) digit changes up as the increase passes from 9 to Ø,
and down as the decrease passes from Ø to 9.
Leave the value set to + 1.ØØØØØ.
To Next Page
