Flyer Mountain - Bike Fit Adjustments

55
EN
Do not forget to take a high-quality bike
lock with you on the ride so you can park
your FLYER and lock it to an immovable
object. Separately lock the components
that are fastened with quick-release fas-
teners(e.g. the front wheel) as required.
This will prevent theft of these add-on
parts.
12. Afterafall
Have the vehicle and all components checked
for changes, damage, rm attachment and cor-
rect function by a FLYER specialist retailer. This
may, in particular, include dents and cracks in the
frame and fork, bent components and parts such
as the handlebars or a shifted or turned seat.
Inspection by a FLYER specialist retailer must
cover the following main points:
• Carefully check the frame and fork. Deforma-
tions can usually be detected when looking at
surfacesfromdi󰀨erentangles.
• Are the seat, seat post, stem and handlebars
still in their correct positions? If this is not the
case, do NOT move the components back
from their changed position before loosening
the relevant screw connection. It is essential
to adhere to the prescribed fastening torque.
Values and information are provided in the se-
parate “Technical Data” operating instructions
document.
• Check whether both wheels are correctly and
rmlyattachedtotheframeandfork,thatboth
thefrontandrearwheelsrotatefreely.Experts
can see from the distance between the frame
or fork and the wheel whether the wheel turns
without snagging.
• Check that both brakes are operating fully.
• Do not set o󰀨 again without having checked
that the chain is sitting securely on both the
front chain wheel and rear sprockets. It must
be engaged fully with the cogs. If youseto󰀨
andthechainjumpso󰀨acogyoumayfall,at
the risk of very severe injury.
• Check whether the display of the FLYER
E-Bike shows a fault message or a warning.
Do not drive your FLYER when a warning is
displayed. Contact your FLYER specialist re-
tailer immediately.
• Check that the display and the battery are un-
damaged. Do not ride your FLYER if there are
any noticeable changes (cracks, scratches,
etc.).Haveallpartsandfunctionscheckedrst
by your FLYER specialist retailer.
There is a risk that humidity or water
may penetrate the motor if the housing
of your battery is cracked. This may lead
to short circuits or electrical shocks. Im-
mediately stop using the battery in this
case and contact your FLYER specialist
retailer. Do not charge the battery.
If you notice any changes to your E-Bike, DO
NOT continue cycling. Do not retighten any loose
partswithoutrstcheckingthemandalwaysuse
a torque wrench. Take the FLYER to your FLYER
specialist retailer, describe the fall to them and
have the bicycle checked out.
13. Adjusting the
bike to the rider
Installing pedals
Always have your pedals installed or changed by
your FLYER specialist retailer, and feel free to ask
for advice on correct handling.
Pedals must be installed with a suitable spanner.
Please note that the two pedals are screwed on
indi󰀨erentdirectionsandmustbefastenedwith
high torque (See the separate “Technical Data”
operating instructions document.). Apply assem-
bly grease to both threads.
Pleasetake note thatthe right pedalis di󰀨erent
from the left. You can recognise which pedal be-
longs on which side from the screws which turn in
opposite directions. Usually, an “R” is embossed
on the right pedal and an “L” on the left. Screw the
right pedal clockwise and the left pedal anti-clock-
wise into the cranks.
The pedals must be fastened with a suit-
able spanner. Observe the correct fas-
tening torque when attaching the pedals.
Ensurethatthepedalsarettedstraight
(See the separate “Technical Data” op-
erating instructions document). If they
arettedatanangle,thereisadanger
that they will break and cause a fall.
(See the separate “Technical Data” op-
erating instructions document.)
For safety reasons, we strongly advise
not using pedals with clips or straps.
