5.27 Downtubebattery
SIB down tube battery
Check the battery before you charge it
forthersttimeoruseitinyourFLYER
e-bike.
Completely charge the battery using the
chargerbeforetherstridetoensurefull
battery performance. Read and adhere
to the operating instructions for the
charger when charging the battery.
Charging status indicator
The main menu “Drive” on your display contains
a symbol that indicates the battery charge level,
which is also shown as a percentage.
In all other menus, the charge level is displayed
as a symbol in the top-left.
If the charge level is less than 20%, the battery
is red.
Batterychargelevelcheck
Akkuladestandsanzeige
Jede leuchtende Akkuladestandsleuchte steht für ca. 20 % der Akkukapazität.
Akkuladestandsleuchten
5 an
4 an 3 an 2 an
1 an 1 blinkt*
1
5 an 4 an 3 an 2 an 1 an 1 blinkt*
1
Anteil der Akkukapazität
im Vergleich zum voll
geladenen Akku
81 % bis 100 % 61% bis 80% 41% bis 60% 21% bis 40% 11% bis 20% 1% bis 10%
*
1
Wenn keine Restkapazität mehr im Akku vorhanden ist, blinkt eine Akkuladestandsleuchte schnell.
Akkuladestandsanzeige
Jede leuchtende Akkuladestandsleuchte steht für ca. 20 % der Akkukapazität.
Akkuladestandsleuchten
5 an
4 an 3 an 2 an
1 an 1 blinkt*
1
5 an 4 an 3 an 2 an 1 an 1 blinkt*
1
Anteil der Akkukapazität
im Vergleich zum voll
geladenen Akku
81 % bis 100 % 61% bis 80% 41% bis 60% 21% bis 40% 11% bis 20% 1% bis 10%
*
1
Wenn keine Restkapazität mehr im Akku vorhanden ist, blinkt eine Akkuladestandsleuchte schnell.
1LEDbatterychargeindicator
Shows the e-bike battery’s remaining capacity.
If an error occurs, an error code is displayed (see
Chapter 5.29 Battery error codes)
2Controlbuttonforbatterychargelevel
Let the LED battery charge level indicator blink to
verify the remaining battery capacity.
3 Charger connector
4 Rubber cap
Protects the charger connectors when the battery
is not being charged.
To check if the battery is charging, press the control
button on the battery to be shown the charge level.
Chargethebatterywhennotallofthevecharge
indicator LEDs light up. Only use the original
charger.
Never use chargers supplied by other manufac-
turers!
Afast-ashingLEDindicatesthatthebatteryhas
been completely discharged.
Removingthebattery
1. Switcho󰀨theelectricalsystemrst.Todothis,
presstheon/o󰀨buttononthedisplay.
2. Unlock the battery with the battery key and re-
moveitfromtheholder.Holdthebatteryrmly,
as it is heavy.
