Circuits protectedAmpere ratingFuse

Heater control, steering

column, DPF, remote

control receiver, DVD

player,

10102

Lighting control battery

supply

10103

Battery saver, interior

lamps

10104

Heated rear window25105

Not used-106

Instrument cluster

battery supply, on-board

diagnostics

10107

Accessory to cluster

(audio and navigation

unit)

7.5108

Cigar lighter, rear auxil-

iary power socket

20109

Daytime running lamps

ignition supply to lighting

control switch

10110

Fuel pump15111

Audio modules battery

supply

15112

Daytime running lamps

(parking lamps)

10113

Instrument cluster igni-

tion supply, engine

immobiliser

10114

Lighting control ignition

supply

7.5115

182

Fuses
