Circuits protected
Ampere rating
Fuse
Fog lamps
20
116
Number plate lamps
7.5
117
Door module, left-hand
rear
20
118
T
railer tow module,
luggage compartment
auxiliary power socket
25
119
Door module, right-hand
rear
20
120
Heated front seats
20
121
Airbag module
10
122
Heated exterior mirrors
7.5
123
Parking lamps, side
lamps, tail lamps (left-
hand side)
7.5
124
Parking lamps, side
lamps, tail lamps (right-
hand side)
7.5
125
Key free system
20
126
Electric windows,
cooling unit
25
127
Not used
-
128
Windscreen wipers
20
129
Not used
-
130
Rear window wiper
15
131
Brake lamps
15
132
Central locking relays,
passenger door module
25
133
183
Fuses
184
186
