Circuits protected
Ampere rating
Fuse
Central locking, driver
door module
20
134
Daytime running lamps
20
135
Washer pump, heated
washer jets
15
136
Battery backup sounder
,
electric folding mirrors
10
137
Powertrain control
module, accelerator
pedal, automatic trans-
mission
10
138
Main beam right-hand
side
10
139
Main beam left-hand
side
10
140
Reversing lamp, electric
mirrors
10
141
Dipped beam, right-
hand side
15
142
Dipped beam, left-hand
side
15
143
184
Fuses
185
187
Table of Contents
Default Chapter
3
Table of Contents
3
Introduction
9
About this Handbook
9
Symbols Glossary
9
Parts and Accessories
9
Quick Start
12
Child Safety
22
Child Seats
22
Child Seat Positioning
23
Child Safety
24
Booster Cushions
25
Booster Seat
25
ISOFIX Anchor Points
26
Child Safety Locks
28
Occupant Protection
29
Principle of Operation
29
Occupant Protection
30
Seat Belts
32
Fastening the Seat Belts
33
Seat Belt Height Adjustment
35
Using Seat Belts During Pregnancy
35
Disabling the Passenger Airbag
35
Keys and Remote Controls
37
General Information on Radio Frequencies
37
Programming the Remote Control
37
Changing the Remote Control Battery
38
Locks
38
Remote Control Type
38
Opening the Container
39
Replacing the Battery
40
Keys and Remote Controls
41
Locks
42
Locking and Unlocking
42
Central and Double Locking
43
Keyless Entry
46
Unlocking the Vehicle
49
Locking the Vehicle
51
Global Opening and Closing
52
Global Closing
52
Engine Immobiliser
54
Principle of Operation
54
Coded Keys
54
Arming the Engine Immobiliser
54
Disarming the Engine Immobiliser
54
Alarm
55
Arming the Alarm
55
Automatic Arming Delay
55
Interior Sensors
55
Disarming the Alarm
56
Britain and Ireland Only
56
Steering Wheel
57
Adjusting the Steering Wheel
57
Horn
57
Audio Control
57
Steering Wheel
58
Voice Control
59
Pedals
60
Adjusting the Pedals
60
Wipers and Washers
61
Windscreen Wipers
61
Wipers and Washers
62
Windscreen Washers
63
Rear Window Wiper and Washers
63
Reverse Gear Wipe
63
Adjusting the Windscreen Washer Jets
64
Headlamp Washers
64
Checking the Wiper Blades
65
Changing the Wiper Blades
65
Lighting
66
Lighting Control
66
Headlamp Flasher
66
Lighting Control Positions
66
Autolamps
67
Front Fog Lamps
67
Rear Fog Lamps
67
Headlamp Levelling
68
Adaptive Front Lighting System (AFS)
70
Hazard Warning Flashers
72
Direction Indicators
73
Interior Lamps
74
Courtesy Lamp
74
Reading Lamps
74
Changing a Bulb
76
Side Repeaters
79
Rear Lamps
82
Central Brake Lamp
83
Luggage Compartment Lamp
84
Windows and Mirrors
86
Electric Windows
86
Exterior Mirrors
87
Convex Mirrors
87
Electric Exterior Mirrors
88
Interior Mirror
89
Instruments
90
Gauges
90
Warning Lamps and Indicators
92
Abs Warning Lamp
92
Fuel Gauge
92
Airbag Warning Lamp
92
Brake System Warning Lamp
92
Doors Open Warning Lamp
93
Engine Warning Lamp
93
Cruise Control Indicator
93
Front Fog Lamp Indicator
93
Direction Indicator
93
Oil Pressure Warning Lamp
95
Power Steering Warning Lamp
95
Stability Control (Esp) Indicator
95
Rear Fog Lamp Indicator
95
Audible Warnings and Indicators
96
Key Outside Car
96
Lights on
96
Low Fuel
96
Information Displays
98
General Information
98
Information Displays
99
Personalised Settings
101
Units of Measure
102
Language Setting
102
Clock Setting
102
Auxiliary Heater Programming
102
Chime Deactivation
104
Information Messages
105
Climate Control
109
Principle of Operation
109
Air Vents
109
Manual Climate Control
110
Recirculated Air
111
Rapid Heating of Vehicle Interior
111
Climate Control
112
Automatic Climate Control
113
To Switch Mono Mode Back on
114
Mono Mode
114
To Switch Mono Mode off
114
Air Distribution
114
Windscreen Defrosting and
115
Heated Windows and Mirrors
116
Auxiliary Heater
116
Programmable Auxiliary Heater
116
Electric Sunroof
118
Fuel Operated Heater
118
Sunroof Anti-Trap Protection
120
Sunroof Safety Mode
120
Sunroof Relearning
120
Seats
122
Sitting in the Correct Position
122
Manual Seats
122
Head Restraints
123
Electric Seats
124
Rear Seats
126
Comfort Seat System
126
Folding the Seatbacks Forward
127
Folding the Seats Forward
129
Removing the Seats
132
Installing the Seats
133
Heated Seats
134
Convenience Features
135
Sun Visors
135
Sun Blinds
135
Instrument Lighting Dimmer
136
Cigar Lighter
136
Auxiliary Power Sockets
136
Centre Console
137
Front Seat Centre Console
137
Rear Seat Centre Console
138
Cool Box
139
Storage Compartments
139
Front Storage Compartment
139
Seat Back Trays
140
Glasses Holder
141
Toll Reader
141
Childminder Mirror
142
Auxiliary Input (AUX IN) Socket
142
Starting the Engine
143
General Information
143
Ignition Switch
143
Steering Wheel Lock
144
Starting a Petrol Engine
144
Vehicles with a Flexfuel Engine
145
Starting a Diesel Engine
146
Cold/Hot Engine
146
Keyless Starting
147
Starting the Engine
148
Failure to Start
149
Switching off the Engine
150
Engine Heater
150
Fuel and Refuelling
151
Safety Precautions
151
Fuel Quality - Petrol
151
Fuel Quality - Flexible Fuel
151
Fuel Quality - Diesel
152
Catalytic Converter
152
Fuel Filler Flap
153
Refuelling
153
Fuel Consumption
153
Technical Specifications
154
Fuel and Refuelling
155
Transmission
156
Manual Transmission
156
Automatic Transmission
156
Selector Lever Positions
157
Drive Modes
158
Brakes
160
Principle of Operation
160
Hints on Driving with ABS
160
Parking Brake
161
Stability Control
162
Principle of Operation
162
Using Stability Control
163
Parking Aid
164
Principle of Operation
164
Using the Parking Aid
164
Parking Aid
165
Cruise Control
166
Principle of Operation
166
Using Cruise Control
166
Cruise Control
167
Automatic Speed Limiter (ASL)
168
Principle of Operation
168
Load Carrying
169
General Information
169
Luggage Covers
169
Rear under Floor Storage
170
Towing
171
Towing a Trailer
171
Detachable Tow Ball
171
Steep Gradients
171
Inserting the Tow Ball Arm
172
Driving with a Trailer
173
Driving Hints
175
Running-In
175
Emergency Equipment
176
First Aid Kit
176
Warning Triangle
176
Status after a Collision
177
Fuel Cut-Off Switch
177
Inspecting Safety System Components
177
Fuses
178
Fuse Box Locations
178
Auxiliary Fuse Box
178
Left-Hand Drive
178
Right-Hand Drive
178
Changing a Fuse
179
Fuse Labels
179
Central Fuse Box
179
Fuse Specification Chart
181
Engine Junction Box
181
Vehicle Recovery
187
Towing Points
187
Front Towing Eye
187
Towing the Vehicle on Four Wheels
188
Rear Towing Eye
188
Vehicle Recovery
189
Maintenance
190
General Information
190
Opening and Closing the Bonnet
191
Engine Compartment Overview - 1.6L Duratec-16V (Sigma)/1.6L Duratec-16V Ti-VCT (Sigma)
192
Engine Compartment Overview - 1.8L Duratec-HE (MI4)/2.0L Duratec-HE (MI4)
194
Engine Compartment Overview - 1.6L Duratorq-Tdci (DV) Diesel
196
Engine Compartment Overview - 1.8L Duratorq-Tdci (Lynx) Diesel
198
Engine Compartment Overview - 2.0L Duratorq-Tdci (Puma) Diesel
200
Engine Oil Dipstick - 1.6L
201
Duratec-16V Ti-VCT (Sigma)
201
Engine Oil Dipstick - 1.8L Duratec-HE (MI4)/2.0L Duratec-HE (MI4)
201
Engine Oil Dipstick - 1.6L Duratorq-Tdci (DV) Diesel
202
Engine Oil Dipstick - 1.8L Duratorq-Tdci (Lynx) Diesel
202
Engine Oil Dipstick - 2.0L Duratorq-Tdci (DW) Diesel
202
Engine Oil Check
202
Engine Coolant Check
203
Brake and Clutch Fluid Check
204
Power Steering Fluid Check
204
Washer Fluid Check
205
Technical Specifications
205
Technical Specifications
206
Vehicle Care
209
Cleaning the Exterior
209
Cleaning the Rear Window
209
Cleaning the Chrome Trim
209
Body Paintwork Preservation
209
Cleaning the Headlamps
209
Cleaning the Interior
210
Repairing Minor Paint Damage
210
Vehicle Battery
211
Battery Care
211
Using Booster Cables
211
To Connect Booster Cables
211
To Start the Engine
212
Changing the Vehicle Battery
212
Wheels and Tyres
213
General Information
213
Changing a Road Wheel
213
Spare Wheel
213
Vehicle Jack
214
Jacking and Lifting Points
215
Wheels and Tyres
216
Removing a Wheel
217
Fitting a Wheel
218
Tyre Repair Kit
219
Using the Tyre Repair Kit
220
Inflating the Tyre
220
Checking the Tyre Pressure
224
Tyre Care
225
Using Winter Tyres
225
Using Snow Chains
225
Technical Specifications
226
Vehicle Identification
228
Vehicle Identification Plate
228
Vehicle Identification Number (VIN)
228
Engine Number - 1.6L Duratec-16V (Sigma)/1.6L Duratec-16V Ti-VCT (Sigma)
228
Engine Number - 1.8L Duratec-HE (MI4)/2.0L Duratec-HE (MI4)
228
Engine Number - 1.6L Duratorq-Tdci (DV) Diesel/2.0L Duratorq-Tdci (Puma) Diesel
229
Engine Number - 1.8L Duratorq-Tdci (Lynx) Diesel
229
Technical Specifications
230
Telephone
233
General Information
233
Telephone Setup
233
Making a Phone an Active Phone
234
Phonebook Categories
234
Bond Another Bluetooth Phone
235
Handling of Phones
235
Requirements for Bluetooth Connection
235
Bluetooth Setup
235
Telephone Controls
236
Using the Telephone - Vehicles Without: Navigation System
237
Using the Telephone - Travel Pilot EX
240
Handling an Incoming Call
241
Voice Control
243
Principle of Operation
243
Using Voice Control
244
Audio Unit Commands
244
System Operation
244
CD Player/CD Changer
244
Telephone Commands
249
Create a Phonebook
250
Phone Functions
251
Main Settings
253
Navigation System Commands
254
Climate Control Commands
254
Appendices
257
Type Approvals
257
Electromagnetic Compatibility
264
Other manuals for Ford C-MAX
Owner's Manual
316 pages
Quick Reference Guide
17 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Ford C-MAX and is the answer not in the manual?
Ask a question
Ford C-MAX Specifications
General
Brand
Ford
Model
C-MAX
Category
Automobile
Language
English
Related product manuals
Ford C-MAX 2016
17 pages
Ford 2011 C-Max
300 pages
Ford C-MAX 2014
10 pages
Ford C-MAX 2010
298 pages
Ford focus c-max
296 pages
Ford C-MAX HYBRID
447 pages
Ford C-MAX ENERGI
447 pages
Ford 2015 C-MAX HYBRID
469 pages
Ford 2013 C-Max Hybrid
524 pages
Ford 2013 C-MAX ENERGI
524 pages
Ford C-MAX HYBRID 2015
455 pages
Ford C-MAX Hybrid 2013
446 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
