MANTIS BACK
Chip Changers Using the chip changers, the MANTIS can automatically dispense up
to six reagents without user intervention. The chip changers are
compatible with High Volume (HV), Low Volume (LV), High Volume
PFE, Low Volume PFE, or High Volume Continuous Flow (CF) chips.
Plate Clamps
Located on the lower-right of the plate holder, the plate clamps align
and secure the plate during the dispensing process.
Plate Holder The plate holder is compatible with almost all SBS plate types and
deep well blocks.
Tube Holder The tube holders are compatible with 50 mL Falcon tubes that are
ideal for large volume dispenses or frequently used reagents.
Waste Station The waste station is a station for the MANTIS to deposit waste
liquids.
Wash Stations The wash stations are where the MANTIS hold wash solutions and
water, used during the chip washing process. If you are running 3-
step Wash, wash solution should go in Wash Station 2, on the right
side of the MANTIS with the two chip stations. Otherwise, it can go in
Wash Station 1.
MANTIS User's Guide | Chapter 5: Hardware Overview
MANTIS Back View
Waste Station
Wash Station 1
Wash Station 2
USB Ports
Power Switch
Power Port
