29
MANTIS User's Guide | Chapter 6: Initial Setup
Pipette Tip Input Source Type
Input Source Type Default volume values for pipette tip input source
Chip Type Low Volume High Volume
Low Volume
PFE
High Volume
PFE
Prime Volume (µL) 6 16 6 16
Pre-Dispense Volume
(µL)
0.6 6 0.6 6
Recovery Volume (µL) 6 16 6 16
Wash Volume 1 (Station
1)
6 16 6 16
Wash Volume 2 (Station
2)
6 16 6 16
Wash Volume 3 (Station
3)
6 16 6 16
Note
: We provide these screenshots for general reference. The default values
recommendation varies, depending on the input source type and chip type
selected.
Pipette Tip - Low Volume PFE Chip Type
