Fox FT2 User Manual

Model FT2 101364
4. Programming
4.1. Programming using the Local Display
4.1.1. Data Entry using the local display module
There are 2 basic types of menu entries: one for changing value or string and one for selecting
from a selection list.
4.1.1.1. To Change a Value or String :
Press CHG (F1) key to change the value, OK (F4) to accept the value.
Press the UP (F1) or DN (F2) key to select a new digit or character, the cursor points to
the selected digit. Press NXT (F3) to select the next digit and OK (F4) to accept the
entry.
Note: If the UP (F1) or DN (F2) key is held down for more the 1 second, the program
will progressively select new digits at increasing speed as time increases.
VALUE = 0.91234
CHG OK
F1 F2 F3 F4
VALUE = 0.91234
UP DN NXT OK
F1 F2 F3 F4
4.1.1.2. To Select from a List:
Press NXT (F1) key repeatedly until the correct selection is made and OK (F4) key to
accept the entry.
FLO UNT = SCFM
NXT OK
F1 F2 F3 F4
Page 28 Fox Thermal Instruments, Inc., 399 Reservation Road, Marina, CA 93933
