4.1.2. Entering the Programming Mode

To enter the programming mode, press the F1 or F2 key repeatedly in the normal running mode

until the following screen is shown:

SET PARAMETERS ?

No Yes

F1 F2 F3 F4

Press YES (F4) and the following screen will prompt the user to enter the password if it is active:

PASWD:_

UP DN NXT OK

F1 F2 F3 F4

Enter the correct password, follow the instructions for changing a value as specified in section

4.1.1. The default Level 1 password is “1234”.

If the wrong password is entered, the message “Wrong Password” will be displayed for a few

seconds and then returns to the programming entry screen.

If the password is accepted, the following screen will be shown:

SET PARAMETERS

I/O FLO DSP EXIT

F1 F2 F3 F4

This is the base screen for the programming mode.

Press EXIT (F4) repeatedly until “Normal Mode” is seen briefly to exit the programming

mode.

4.1.3. Analog 4-20 mA Output

The following menu allows the scaling of the analog 4-20 mA outputs.

From the base screen, press I/O (F1) and then in the next screen press 420 (F3).

SET I/O

I/O FEQ 420 EXIT

F1 F2 F3 F4

Fox Thermal Instruments Inc., 399 Reservation Road, Marina, CA 93933 Page 29
