101364 Model FT2
Use the CHG (F1) key to change the entry, PRV (F2) to move to the previous entry, NXT (F3) to
move to the next entry and EXIT (F4) to return.
The calibration table can hold up to 20 data pair points. Each data point has a voltage and mass
velocity associated with it.
Pressing the NXT (F3) key will show the data point voltage and then mass velocity and then go to
the next data point. The number after Volt (ie.Volt1) or Flo (i.e. Flo1) indicated the data point
number.
Upon exiting the menu, the display will prompt for a calibration date as follows:
CalDate=2/24/03
CHG OK
F1 F2 F3 F4
4.1.12. Reset Total and Elapsed Time
The resetting of the totalizer and elapsed time is accomplished by pressing the F3 and F4 keys at
the same time in the normal running mode.
RESET TOTAL ?
NO YES
F1 F2 F3 F4
Press YES (F4) to reset total and NO (F1) to cancel.
If you entered the programming menu with a Level 2 password,
The following menu Restore Database will be displayed:
4.1.13. Restore Database
Restoring the original factory settings is accomplished from the “Flow Parameter 2” menu
by entering a Level 2 password “9111” and pressing the SPC key (F2).
RESTORE DATABASE ?
YES NO
F1 F2 F3 F4
Press YES (F1) ONLY if you want to restore your database to the initial factory setting that the
meter was shipped with. All current user-entered settings will be overwritten.
4.1.14. Reset CRC
If the EEPROM CRC check fails (Error Code 36), the EEPROM values will need to be verified
and corrected before clearing the error. Call FOX Customer Service if you need assistance.
Fox Thermal Instruments Inc., 399 Reservation Road, Marina, CA 93933 Page 43
