Note: When the flow rate exceeds the maximum frequency set point, the output will stay at that

maximum frequency but the FT2 will issue an alarm code.

4.1.5. Discrete Input/Output

To program the discrete input or output, press I/O (F1) key from the base menu

SET I/O

I/O FEQ 420 EXIT

F1 F2 F3 F4

Then press I/O (F1) again:

SET I/O

COM CTC EXIT

F1 F2 F3 F4

Then press CTC (F2) to select contact input/output

CONTACTS

INP ALM EXIT

F1 F2 F3 F4

4.1.5.1. For Discrete Input Settings:

Press INP (F1) key to select input, then menu will display:

INP = Not Used

NXT OK

F1 F2 F3 F4

Press NXT (F1) repeatedly until the correct selection is shown and then press OK (F4) to

accept the setting.

Selections are: Not used

Tot Reset to reset the totalizer

Switch Crv Multi Curve Option Only
