Then select either FLO (F1) or TMP (F2) for flow rate or temperature channel.

SET 4-20 MA

FLO TMP EXIT

F1 F2 F3 F4

20 mA = 3751 SCFM

CHG OK

F1 F2 F3 F4

Enter the value for the 20 mA and press OK (F4) key to accept setting.

Then the following screen will show:

4 mA = 0 SCFM

CHG OK

F1 F2 F3 F4

Enter the value for the 4 mA and press OK (F4).

Note: 4 mA is normally set to 0.

Press EXIT (F4) repeatedly until “Normal Mode” is seen briefly to exit the programming mode.

Note: When the flow rate exceeds the programmed value for the 20 mA set point, the analog

output will stay at 20 mA and an alarm code will be generated.

4.1.4. Frequency Output

The frequency output can be configured in three different ways: (1) specifying a maximum

frequency to a defined maximum value of flow rate, (2) specifying how many flow unit total per

pulse, U/P (i.e. 0.1 lb per pulse) or (3) specifying how many pulses per unit, P/U, of mass. All

these approaches are equivalent.

From the base screen, press I/O (F1) and then FEQ (F2)

FREQUENCY OUTPUT

P/U U/P FEQ EXIT

F1 F2 F3 F4

Use P/U (F1) to enter pulse per unit, U/P (F2) for Unit per pulse and FEQ (F3) to enter the flow

and maximum frequency to scale the frequency output.
