When data is entered with any of the 3 methods, the other values will be re-calculated according to
the settings.
4.1.4.1. Entering data in Pulse per Unit:
Press P/U (F1) and the following screen will show:
PLS/UNT = 100
CHG OK
F1 F2 F3 F4
Press CHG (F1) to change the setting and then OK (F4) to accept entry.
The value entered is in pulse per selected flow unit total (i.e. 10 pulses per SCF)
4.1.4.2. Entering data in Unit per Pulse:
Press U/P (F2) and the following screen will show:
UNT/PLS = 0.01
CHG OK
F1 F2 F3 F4
Press CHG (F1) to change the setting and then OK (F4) to accept entry.
The value entered is in unit per pulse (i.e. 0.01 flow unit total per pulse)
4.1.4.3. Entering data with flow and maximum frequency:
Press FEQ (F3) and the following screen will show:
MaxFreq=98.52 Hz
CHG OK
F1 F2 F3 F4
Enter the maximum frequency and press OK (F4)
(Maximum frequency should not exceed 100 Hz)
The next screen will show:
Maxflo=2000 SCFM
CHG OK
F1 F2 F3 F4
Fox Thermal Instruments Inc., 399 Reservation Road, Marina, CA 93933 Page 31
