Model FT2 101364

Press YES (F1) ONLY if you want to reset the CRC and generate a new CRC value.

RESET CRC?

YES NO

F1 F2 F3 F4

4.1.15. Simulation

This menu allows for the simulation of flow rate, temperature and flow input voltage. It should

only be used for testing and demonstration purposes.

Make sure to return all of these simulation values to zero, before returning to

the normal mode of operation.

Note: Simulated values are only enabled when not set to zero.

Caution:

If the 4 to 20 mA and/or the pulse outputs are connected to controllers, set the controllers to

“manual”. This will ensure that the simulated signals do not cause false controller action.

The menu is accessible from the main programming menu by pressing FLO, and SIM:

FLOW PARAMETER 1

SIM UNT PRM EXIT

F1 F2 F3 F4

Pressing SIM (F1) will show:

FloSim = 0 SCFM

CHG OK

F1 F2 F3 F4

Enter the value and then press OK (F4).

Note: Enter zero to disable this feature.

TmpSim = 0 C

CHG OK

F1 F2 F3 F4

Enter the value and then press OK (F4).

Note: Enter zero to disable this feature.

Page 44 Fox Thermal Instruments, Inc., 399 Reservation Road, Marina, CA 93933

Fox FT2 User Manual
