QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 20
RETURN Alarms & Shutdowns - Page 3 data: $01F3
Command structure:
Command Description
$ Start of command sequence.
xx Quantum ID code.
F3 Failure Annunciation command Page 3.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Character
Position
Description of returned data
1 A = Acknowledge
2-3 xx = Quantum ID code
4-7 Message Code 1
8-15 Date 1 as mm/dd/yy
16-23 Time 1 as hh:mm:ss
24 Space
25-28 Message Code 2
29-36 Date 2 as mm/dd/yy
37-44 Time 2 as hh:mm:ss
45 Space
46-49 Message Code 3
50-52 Date 3 as mm/dd/yy
53-65 Time 3 as hh:mm:ss
66 Space
67-70 Message Code 4
71-78 Date 4 as mm/dd/yy
79-83 Time 4 as hh:mm:ss
84 Space
85-91 Message Code 5
92-99 Date 5 as mm/dd/yy
100-107 Time 5 as hh:mm:ss
108 Space
109-112 Message Code 6
113-120 Date 6 as mm/dd/yy
121-128 Time 6 as hh:mm:ss
129 Space
130
CS (Checksum followed by Carriage return,
Line feed.)
RETURNED ANSWER,
Character
Position
Description of returned data
1 A = Acknowledge
2-3 xx = Quantum ID code
4-7 Message Code 1
8-15 Date 1 as mm/dd/yy
16-23 Time 1 as hh:mm:ss
24 Space
25-28 Message Code 2
29-36 Date 2 as mm/dd/yy
37-44 Time 2 as hh:mm:ss
45 Space
46-49 Message Code 3
50-52 Date 3 as mm/dd/yy
53-65 Time 3 as hh:mm:ss
66 Space
67-70 Message Code 4
71-78 Date 4 as mm/dd/yy
79-83 Time 4 as hh:mm:ss
84 Space
85-91 Message Code 5
92-99 Date 5 as mm/dd/yy
100-107 Time 5 as hh:mm:ss
108 Space
109-112 Message Code 6
113-120 Date 6 as mm/dd/yy
121-128 Time 6 as hh:mm:ss
129 Space
130
CS (Checksum followed by Carriage return,
Line feed.)
