QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 21
RETURN DATA VALUE FROM TABLE $IDER
$ Start of command sequence
ID Quantum ID code.
ER Return the value of a Table address.
00000 Frick Address(s) of data value in Table
up to 32 different addresses can be re-
quested
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Starting
Character
Position
Description of returned data
1 A = Acknowledge
2-3 xx = Quantum ID code.
4
Value(s) of requested data.
CS (Checksum followed by
Carriage return, Line feed.)
CHANGE SETPOINT COMMAND: $IDEW
$ Start of command sequence.
ID Quantum ID code.
EW Change Table address’s setpoint value.
00000 Frick’s Table address of the setpoint.
000000000
New setting scaled x100. followed by the
“CS”,”CR”
RETURNED ANSWER: - “A” followed by the “ID”,
and 1 “CR”, “LF” if successful.
and 0 “CR”, “LF” if unsuccessful.
